Line 01 Start here
Every endpoint except /v2/status and /v1/ping wants an
x-api-key header. This shared demo-tier key is the party line:
public by design, because nothing behind it costs real money, and its usage plan (2 requests per
second, 2,500 a day) is the guardrail. Partner-tier keys with higher limits exist but are never
published.
loading…
loading…
The full machine-readable contract is at /openapi.json, the same file Terraform imports into API Gateway. These docs cannot drift from the deployed API.
Line 02 See the governance work
Six live demos against the real gateway. Each shows the exact request sent and the response that came back, including the ones where the switchboard answers before any application code runs.
Why an exchange?
Before dial service, an operator sat between every caller and every line: she answered, checked who you were, refused calls that made no sense, and connected the rest. That is an API gateway's whole job. The board answers first; the offices behind it only ever hear well-formed, authorized, rate-limited calls.
Line 03 API reference
The directory, rendered in your browser from /openapi.json. Every operation has a live try it console. Requests go same-origin to the gateway with the demo key attached.
loading spec…
Line 04 Usage plans & your own line
Three tiers meter the same board: the shared party line every visitor uses, personal lines the exchange installs on request, and private trunks issued per integrator.
| Plan | Steady rate | Burst | Daily quota | Key distribution |
|---|---|---|---|---|
| demo (the party line) | 2 req/s | 5 | 2,500 | Printed above, shared by every visitor |
| visitor (your own line) | 2 req/s | 5 | 500 | Self-issued below; expires after ~24h |
| partner (a private trunk) | 25 req/s | 50 | 50,000 | Issued per integrator, never published |
The key you present decides your limits. Exceed the rate and the gateway
answers 429 throttled, the busy signal. Exhaust the quota and it answers
429 quota_exceeded until midnight UTC. Application code never sees those requests.
Get your own line installed
The exchange will mint you a real API key on the visitor plan,
live, via the keyless POST /v2/platform/keys (you cannot present a key you do not
have yet). It is shown once, goes live within a minute or two as the gateway's key cache picks
it up, and the nightly sweep removes it about 24 hours later. Issuance is capped per address
and per day.
Line 05 Order an export
The asynchronous-job pattern, live: POST /v2/exports answers
202 Accepted immediately with a Location header, the job rides an SQS
queue to a worker Lambda, and the finished file comes back as a presigned S3 URL that expires
after 15 minutes. The bucket itself is never public.
Line 06 How it's built
Each microservice is its own Lambda with an IAM role fenced to its own DynamoDB
table: the permits service cannot read a license record even by bug. The exports worker is the
one deliberate exception — read-only across the catalogs, so the write boundary holds. The docs
site is S3 + CloudFront; the API is served same-origin under /v1/* and
/v2/*, so there is no CORS surface at all. Idle cost of the whole plank: ~$0.
